16′ × 7′6″ × 7′6″
4.88m × 2.29m × 2.29m
≈1,600 lbs flat-packed
30–60 minutes, two people
The 16′ Storage Unit is one of the largest options in the My Yard Vault lineup, designed for industrial operations and commercial environments where high-capacity storage is essential. With approximately 769 cubic feet of interior space, it’s an ideal solution for warehouses, manufacturing facilities, contractors, and large property management operations.
Constructed with 20-gauge corrugated galvanized steel walls and a 16-gauge roof, this unit is engineered to handle demanding conditions while delivering exceptional strength, security, and long-term reliability.
Powder coated inside and out, it stands up to New Mexico sun, wind and weather. Both end-door and side-door configurations are available, so you can put the opening where it suits your site.
| External Length | 16′ 0″ (4.88m) |
| External Width | 7′ 6″ (2.29m) |
| External Height | 7′ 6″ (2.29m) |
| Internal Length | approx. 15′ 6″ (4.72m) |
| Internal Width | approx. 7′ 0″ (2.13m) |
| Internal Height | approx. 7′ 1″ (2.16m) |
| Door Opening | approx. 5′ 9″ W × 6′ 8″ H (1.75m × 2.03m) |
| Cubic Capacity | approx. 769 cu ft (21.8 m³) |
| Flat-Packed Weight | ≈1,600 lbs (726 kg) |
| Assembly | 30–60 minutes, two people, level ground |
| Handling | Forklift pockets; roof lifting lugs for crane placement |
| Wall Material | 20-gauge corrugated galvanized/galvalume steel |
| Roof Material | 16-gauge steel |
| Finish | Powder coated inside and out |
| Locks | Stainless steel, weatherproof |
| Color Options | Light gray, dark gray, cream |
| Warranty | 2-year manufacturer warranty |
Contact our team for detailed specifications, CAD drawings, and custom configuration options.
Approximately 769 cubic feet of secure interior space.
20-gauge corrugated steel walls with a 16-gauge roof, powder coated inside and out.
Available with the door in the end panel or in a side wall.
Panels carry through a standard 24-inch gate and assemble where the vault will sit.
Forklift pockets for easy repositioning, plus roof lifting lugs if a crane is the simpler way in.
Ships as flat steel panels — about 100 lbs per foot of length — on a standard trailer.
Large-scale storage for manufacturing facilities, warehouses, and distribution centers.
Centralized storage for maintenance equipment and supplies across large property portfolios.
Flexible overflow storage that scales with your logistics operations.
Tell us what you need, and we’ll recommend the best configuration for your home or business.
